HEAVY WEIGHT Series
Robust and performing breakers, with all the advantages of the Light weight serie but with more impact power. A truly exclusive silenced version which, due to the specific design of its supporting structure, ensures that acoustic noise levels are reduced to a minimum, the advantages being environmental-friendly and operating ease.
Eco silent series of breakers
Vibro silenced – for very low vibrations
Compact and powerful
Reliable
For excavators ranging from 10 to 35 tons
Specifications
| ECOSILENT MODEL | VERSION | WEIGHT(KG.) | IMPACT ENERGY (Joule) | TOOL DIAMETER |
|---|---|---|---|---|
| OLS 700 | Saddle ** | 700 | 2000 | 95 mm. |
| Plate * | 620 | |||
| OLS 980 | Saddle ** | 970 | 2400 | 105 mm. |
| Plate * | 870 | |||
| OLS 1400 | Saddle*** | 1350 | 3200 | 120 mm. |
| Plate * | 1180 | |||
| OLS 1700 | Saddle*** | 1700 | 4200 | 135 mm. |
| Plate * | 1430 | |||
| OLS 2200 | Saddle*** | 2200 | 5400 | 150 mm. |
| Plate * | 1850 | |||
| Note : | ||||
| All Hammers are supplied with: conical tool, one box of lubricating grease, operating and maintenance manual and EC declaration of conformity | ||||
| *FLAT Plate : Customer has to match the equipment saddle as needed. | ||||
| ** Saddle: Customer to provide details of carrier to build custom saddle | ||||
| For optional tools and accessories contact Rotair | ||||
